| Place of Origin: | China |
|---|---|
| Brand Name: | KingPo |
| Certification: | ISO 17025 Calibration certificate |
| Minimum Order Quantity: | 1 |
| Price: | To be quoted |
| Packaging Details: | safety wooden box |
| Delivery Time: | 30 working days |
| Payment Terms: | 100% TT in advance |
| Supply Ability: | 3 units per month |
| Model: | JIS-800 | Internal: | 800*1000*1000 |
|---|---|---|---|
| External: | 1040*1450*1960 | Heating System: | Independent Nichrome Electronic |
| External Material: | Independent Nichrome Electronic | Interface: | RS232 |
| High Light: | EN 6052 Environmental Test Chambers,IEC60529 Environmental Test Chambers,RS232 Sand Dust Test Chamber |
||
IEC60529 EN6052 Environmental Test Chambers PC Link RS232 Interface
JIS-D0207-F2 Sand Dust Test Chamber
1. Description of JIS-D0207-F2 Sand Dust Test Chamber
Standard:IEC60529/EN 6052
Function:These test chambers are used for evaluating the effects of dust-filled environments in order to validate product seal integrity.
Application:Dust test chambers are utilized in automotive,electrotechnical products,materials,coatings,solar energy,etc.
2. Features of JIS-D0207-F2 Sand Dust Test Chamber
• Dust re-cycle blowing by circulating pump.
• Dust collection section is located on bottom of test chamber.
• A heater fixed into test chamber to keep dust dry.
• A viewing window with a manually controlled wiper.
• Programmable color display touch screen controller
• A stainless steel shelf for placing test specimens.
• Test chamber internal illumination
• Vacuum system for specimen
• Bottom install 4 castors for ease moving, andwith brakes function
• Safety protection
• Easy to operate
• Standard: IEC60529
3. Technical Parameter of JIS-D0207-F2 Sand Dust Test Chamber
|
Model |
JIS-800 |
JIS-1000 |
JIS-1500 |
JIS-2000 |
|
Internal dimensions (mm) |
800*1000*1000 |
1000*1000*1000 |
1000*1500*1000 |
1200*1800*1200 |
|
Overall dimensions (mm) |
1040*1450*1960 |
1200*1450*1960 |
1250*1900*1960 |
1500*2200*2160 |
|
Temperature range |
Ambient to +50℃ |
|||
|
Normal wire diameter |
50um |
|||
|
Normal width of a gap between wire |
75um |
|||
|
The Talcum powder amount |
2kg ~ 4kg/m3 |
|||
|
Fight time |
0 ~ 99H59M |
|||
|
Fan cycle time |
0 ~ 99H59M |
|||
|
Specimen power outlet |
Dust-proof socket AC220V 16A |
|||
|
Controller |
programmable color display touch screen controller |
|||
|
PC Link, RS232 interface |
||||
|
Heating system |
Independent Nichrome electronic heating system |
|||
|
Exterior material |
Steel Plate with protective coating |
|||
|
Interior material |
SUS304 stainless steel |
|||
|
Power supply |
380V 50HZ |
|||
4.Packaging
